BATERÍAS DE LITIO

Las baterías de iones de litio, también denominada batería Li-ion, es un dispositivo con dos o tres celdas de energía disecado para el almacenamiento de energía eléctrica que emplea como electrolito. Una sal de litio que consigue los iones necesarios para la reacción electroquímica reversible que tiene lugar entre el cátodo y el ánodo.
Logotipo Lithium Solutions
Model Dimensions
(W*D*H*)
(mm)
Nominal
Capacity
Nominal
Voltage
Discharge
Ending
Voltage
Charging
Limited
Voltage
Display Outer
Package
Max.
Charge
Current
Max.
Discharge
Current
Operation
Charging
Temperature
Discharging
Storage
Temperature
Weight PDF
MC-LFR48-50A 442*
388*
132*
50.0Ah 51.2V 43.2V 57.6V No Material
White
bake
35A 50A 0 ~ 45ºC -20 ~ 60ºC -20 ~ 60ºC 31.5Kg
MC-LFR48-50B 442*
388*
132*
50.0Ah 51.2V 43.2V 57.6V Yes Material
White
bake
10A 50A 0 ~ 45ºC -20 ~ 60ºC -20 ~ 60ºC 32Kg
MC-LFR48-50C 442*
388*
132*
50.0Ah 51.2V 43.2V 57.6V Yes Material
White
bake
50A 50A 0 ~ 45ºC -20 ~ 60ºC -20 ~ 60ºC 31.5Kg
MC-LFR48-100A 442*
388*
220*
100.0Ah 51.2V 43.2V 57.6V No Material
White
bake
65A 75A 0 ~ 45ºC -20 ~ 60ºC -20 ~ 60ºC 57Kg
MC-LFR48-100B 442*
388*
264*
100.0Ah 51.2V 43.2V 57.6V No Material
White
bake
60A 50A 0 ~ 45ºC -20 ~ 60ºC -20 ~ 60ºC 32Kgx2
MC-LFR48-150A 442*
388*
308*
150.0Ah 51.2V 43.2V 57.6V No Material
White
bake
50A 60A 0 ~ 45ºC -20 ~ 60ºC -20 ~ 60ºC 83Kg
MC-LFR48-200A 600*
600*
1050*
200.0Ah 51.2V 43.2V 57.6V No Material
White
bake
40A 100A 0 ~ 45ºC -20 ~ 60ºC -20 ~ 60ºC 178Kg
MC-LFR48-300A 600*
600*
1250*
300.0Ah 51.2V 43.2V 57.6V No Material
White
bake
200A 200A 0 ~ 45ºC -20 ~ 60ºC -20 ~ 60ºC 240Kg
PRUEBA DE RENDIMIENTO DE LA BATERÍA
Item Testing method Requeriment
Performance after of 0.2C discharging After standard charging, discharge at constant current of 0.2 C10 within 1h till terminal voltage reaches 43.2V, record the discharging time. Discharge time 300 min
Performance after of 0.5C discharging After standard charging, discharge at constant current of 0.5 C10 within 1h till terminal voltage reaches 43.2V, record the discharging time. Discharge time ≥ 115 min
Performance of 0.1C discharging After standard charging, discharge at constant current time of 0.1 C10 1within 1h till terminal voltage reaches 43.2V, record the discharging time. Discharge time ≥ 600 min
High temperature performance (60ºC) After standard charging, put battery pack into high-temperature box of 60 ± 2ºC to keep 4h, then discharge at 1.0 C10 till 43.2V at the same temperature, record the discharging time. Discharge time ≥ 54 min
Low temperature performance (-10ºC) After standard charging, put battery pack into high-temperature box of -10 ± 2ºC to keep 6h, then discharge at 0.2 C10 till 43.2V at the same temperature, record the discharging time. Discharge time ≥ 180 min
Low temperature performance (-20ºC) After standard charging, put battery pack into high-temperature box of -20 ± 2ºC to keep 6h, then discharge at 0.2 C10 till 43.2V at the same temperature, record the discharging time. Discharge time ≥ 120 min
